Function control check-out list
In the machine cylinder, you will find the warranty
registration card, a copy of the warranty policy,
the bolt hole template and other pertinent mate-
ria. The warranty card should be completed and
sent to Wascomat. All other items should be
placed in a safe place for future reference.
The machine should be cleaned when the instal-
lation is completed, and checked out as detailed
below without loading the machine with fabrics:
1. Check the incoming power for proper voltage,
phase and cycles.
2. Open manual shut-off valves to the machine.
3. Turn on electric power.
4. Check the door safety interlock as detailed on
page 10 of this manual.
5. Select the HOT program and start the machi-
ne.
6. Run through a complete cycle, checking for
water temperature, drain operation and extract
direction.
7. When the program is in the Soak cycle, hot
and cold water should be entering the machi-
ne. In the Wash cycle only hot water should
enter.
8. If cold water comes in, the hoses are impro-
perly connected. Reverse hot and cold water
hoses.
9. Machine must spin in a counter-clockwise
direction, as seen from the front, during extra-
ction. If it does not, reverse lines L1 and L3.
NOTE
All machines are factory tested prior to
shipment. Occasionally, some residual
water may be found when the machine is
installed.
Installation
20
0985
21
1835
22
1836
23
1188
F
F
F
F
13
