16
A minimum 6 mm ooring grade plywood covering must be installed
in the opposite direction to the Econna-12 panels. This layer must be
screwed into the Econna-12 panels to complete the structural deck.
Step 4 - Lay plywood covering
• Screw the plywood covering into the Econna-12 panels using 25 mm
wood screws, 18 mm in from the edge of each plywood sheet and then at
150 x 150 mm centres, ideally in the centre line between the pipe runs.
2
• Lay a 6 mm ooring grade plywood in the opposite direction to the
Econna-12 panels. The plywood covering should be positioned so that
each plywood panel overlaps the tongue and groove edges of the
Econna-12 panels by 300 mm.
1
It is best practice to predetermine and mark the pipe and screw
positions on the top surface of the ply layer to avoid the straights
and loop ends of the pipe runs.
18 mm 150 mm 150 mm 150 mm 150 mm
