7
Components available from Warmup
Product Code Description
Nexxa
WHS-TL-ALU10
Castellated panel with integrated
10mm insulation
Nexxa Peel & Stick
NEX-P&S
Castellated panel with
self-adhesive backing
Nexxa Insulating & Acoustic
NEX-30
Castellated panel with integrated
30mm insulation with acoustic
properties
WHS-CL-T60 Warmup clips
WHS-P-PERT-xx
xx = length: 25, 50, 60, 70, 80, 90, 100,
110, 120, 300m
PE-RT Pipe- 16mm x 2mm
WHS-P-BEND Pipe bend supports
WHS-CL-CONDUIT
25mm x 50m
Pipe conduit
WHS-X-EDGE50 Warmup perimeter strip
WHS-P-DECOILER Pipe decoiler
WHS-X-POL1200 Polythene DPM; 1200 gauge
WHS-MT-B0xxyy
WHS-MT-B0xxyy+
xx = kpa: 70 / 100
yy = thicknesses: 25, 50, 70, 100mm
+ = 0.030W/mK
EPS Insulation
WHS-MT-INSxx
xx = thicknesses:
25, 30, 40, 50, 60, 70, 75, 80, 90, 100mm
PIR Insulation
Additional components that may be required as part of your
Warmup heating installation:
Manifold, mixing unit, actuators, valves and euroconus connectors
Wiring centre
Warmup thermostats
Electrical trunking/conduit
Digital multi-meter required for testing the resistance of the sensor
Electrical tape to secure the sensor
Screed
