10
Step 1 - Electrical supply
If taking the power supply to the heaters from an existing 30 mA
RCD/RCBO protected circuit, it should be calculated whether or
not the circuit can handle the additional load and if necessary
the supply must be de-rated to ≤ 16 amps�
A junction box is required if more than two heaters are being
connected to a single Warmup thermostat.
When conducting an insulation resistance test on the supply to
the thermostat the thermostat and heaters must be isolated or
disconnected.
1
The supply to the thermostat MUST be protected by a 30mA
RCD or RCBO at all times. Time delay RCD’s or RCBO’s must not
be used. No more than 7.5 kW of heating should be connected
to each 30 milliamp RCD or RCBO. For larger loads, use multiple
RCD’s or RCBO’s.
The heating mats must be separated from the power supply by
suitably rated circuit breaker that disconnects all poles with at
least 3 mm contact separation. Use MCB’s, RCBO’s or fuses for
this purpose�
Final connections to the main electricity supply MUST be
completed by a qualied electrician.
2
Manufactured joints recessed into suboor so as they sit at the
same height as the heater�
3
Sensor installed (300 mm) centrally between two closest parallel
runs of heating cable and away from other heat sources such as
hot water pipes, lighting xtures etc.
2
3
