48
3. INSTALLATION
3.1 Installing the top lid
The top lid hinge spigots are inserted into the plug holes (Fig. 20).
Should the top lids not be parallel, then the spacers supplied with the accessories should
be pushed on to the appropriate spigot as required.
3.2 Choice of pipe connection direction
The pipe is mounted on the back of the stove by the factory.
If a flue gas vent is required on the side of the stove, then the following steps must be
taken:
- removed the pipe connection from the back of the stove (Fig. 21).
- undo the flue hole cover on the side wall about 10-15 turns. Do not take the screw out
completely. Then push the cover down until the fixing bracket is free and the flue hole
cover can be removed (Fig. 22).
- Cut out the aluminium insulation with a knife (Fig. 23).
- Take out the perforated insulating material, if necessary cut it out (Fig. 24).
- Hold the counter cover of the flue hole cover on the inside side wall firmly with the hand
through the rear flue hole opening and removed the flue hole cover (Fig. 25).
- Use the counter cover for the flue hole not being used (Fig. 26), close the flue hole open-
ing with the flue hole cover previously taken off (Fig. 27) and insulate. Use the insulating
material previously removed from the side wall.
- Close the back wall opening with the blind cover supplied (Fig. 28).
- Mount the pipe connection on the selected connection point.
3.3 Installation of the heat exchanger and the heat sink
The heat exchanger and the heat sink are not part of the standard scope of supply of the
central heating stove. If required it can be retrofitted. The following is required:
- Insert the heat sink probe in the fully into the immersion shell (Fig. 29 + 30 C).
- clamp the protective tube firmly in the immersion shell (Fig. 29 + 30 D).
- To install the heat exchanger only the blind flange on the back of the stove needs to be
removed and the heat exchanger connected in its place (Fig. 30 A + 31).
ATTENTION
The heat exchanger has to be firmly bolted to the heating pocket (Fig 31).
Screw thread bolts can strip if too much force is used.
