28
SprayPack 18V
EN
Technical data*
Rechargeable battery (ProCore 18
V, 4.0 Ah):
Li-Ion, 18 V ,
4.0 Ah
Charger (AL 1810 CV):
Input voltage
Output voltage
Charging current
220-240 V
~
, 50-60 Hz;
10.8-18 V
4000 mA
Charging time (rechargeable
battery 18 V, 4.0 Ah):
approx. 48 min
(80%), 65 min (100%)
Protection Class (charger):
/ II
Maximum pressure 11 MPa (110 bar)
Max. delivery rate 0.9 l/min
Maximum temperature of coating
material
43°C
Sound power level**
Uncertainty
75 dBA
K= 4 db
Sound pressure output**
Uncertainty
88 dBA
K= 4 db
Vibration***
Uncertainty
3.8 m/s²
K = 1.5 m/s²
Maximum ambient temperature 40°C
Pump system piston pump
volume upper container, max. 4.7 l
Max. nozzle size 0.017 (inch)
Max. hose length 15 m
Empty weight (pump, hose, gun) 4.2 kg
* When using a ProCore 18 V, 4.0 Ah battery and a
charger GAL 18V-40
** Measured in accordance with EN 50580
*** Measured in accordance with EN 62841-1
Information about the vibration level
The specied vibration level has been measured according
to a standard test procedure and can be used to compare
against electric tools.
The vibration level is also for determining an initial
assessment of the vibrational strain.
Attention! The vibration emission value can dier from
the specied value when the electric tool is actually in
use, depending on how the electric tool is being used.
It is necessary to specify safety measures to protect the
operating personnel. These measures are based on an
estimated shutdown during the actual conditions of use
(all parts of the operating cycle are taken into consideration
here, for example periods when the electric tool is switched
o, and, when it is switched on but running without any
load).
