OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
10.3 MOUNTING MATERIALS
In Chapter 14 the order numbers for device spare parts can be found, as well as for wearing
parts such as seals.
Use torques, greases and glues in accordance with Chapter 14. Spray gun in accordance
with Chapter 10.4.
Mounting materials
Order No. Quantity Designation Smaller tanks
9992511 1 pc ≙ 50 ml Loctite® 243
9992831 1 pc ≙ 50 ml Loctite® 542
9992528 1 pc ≙ 150 g Loctite® 270
9992616 1 pc ≙ 1 kg can Molykote® DX grease 50 g tube ≙ Order No. 2355419
9992698 1 pc ≙ 200 g can Vaseline white, PHHV II
353702 10 ml; 10 cc High-voltage oil
Brand notice
The brands specied in this document are property of the respective owners. Loctite®, for
example, is a registered brand of Henkel.
10.4 SPRAY GUN
Plastic parts
Gently handle all plastic parts.
10.4.1 TOOLS
For disassembling and assembling the spray gun, the following tools are required:
– Allen wrench, SW 2
– Allen wrench, SW 3
– Allen wrench, SW 5
– Wrench, SW 5
– Wrench, SW 6
– Wrench, SW 8
– Wrench, SW 11
– Wrench, SW 12
– Wrench, SW 14
– Wrench, SW 19
– Ring spanner, SW9
– Ring spanner, SW11
– Torx® wrench 20
– Torx® wrench 25
– Screwdriver No. 1
– Slide gauge
– Valve needle assembly tool,
Order No. 2309368
– Clamping screw assembly tool,
Order No. 2325263
Only as required:
– Handle seal assembly tool
(Order No. 2342334, not included in
scope of delivery)
