81
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
9.2 FAULTS IN THE SYSTEM
Functional fault Cause Remedy
Insucient product output – Nozzle too small. – Flat jet: Select larger nozzle
(see nozzle table).
– Product pressure too low. – Increase product pressure.
– Product viscosity too high. – Thin spray product in accordance with
the manufacturer's instructions.
– Filter in paint supply clogged. – Clean or replace lter.
– Nozzle is clogged. – Clean or replace nozzle.
– Product valve travel set too
small.
– Increase product valve travel by turning
the adjusting screw.
Poor spray pattern – Atomizing air incorrectly
adjusted.
– Readjust atomizing air.
– Unfavorable nozzle size. – Select a dierent nozzle
(see nozzle table).
– The product viscosity is too
high.
– Thin product in accordance with the
manufacturer's instructions.
– Product pressure too high/
too low.
– Adapt product pressure.
– Damaged nozzle. – Attach new nozzle.
Poor wrap-around – Poor grounding at object. – Check grounding of object or hanger
with ohmmeter.
– Lacquer resistance
too high/too low.
–
Check lacquer resistance
(see Chapter2.4).
– Spraying pressure too high. – Readjust spraying pressure.
No wrap-around – No high voltage. – Switch on high voltage using push
button.
– Connect gun and gun cable/check for
defect.
–
Check lacquer resistance
(see Chapter2.4).
– Seal in end piece defective. – Repair by WAGNER Service Department.
– Air-passages damp. – Clean and dry air passages.
Back-spray – Object not grounded. – Check grounding.
– Distance between spray gun
and work piece too large.
– Reduce distance between spray gun
and work piece.
– High voltage set wrongly
(too high).
– Adapt high voltage to product.
– Loosen the nozzle union nut
for round jet method.
– Slightly tighten union nut by hand.
Product emission at nozzle
when the gun is closed
– Valve seat leaks, valve seat or
valve tip worn
– Replace valve seat or valve tip.
Product emission from gun – Valve rod packing leaks/
damaged
–
Replace the packing (see Chapter10).
