59
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
Dismount the nozzle
– Flat jet
1. Unscrew the union nut (1) by hand.
2. Remove AF 5000 air cap (4).
3. Unscrew and remove AF 5000 at jet nozzle (5) by hand.
4. Clean the spray gun front carefully with damp cloth.
– AWR 5000 – round jet
1. Unscrew the union nut (1) by hand.
2. Remove AR 5000 air cap (2). Unscrew AWR 5000 nozzle (3) by hand and remove it.
3. Clean the spray gun front carefully with damp cloth.
– EAWRV 5000 – round jet
1. Unscrew the EARV union nut (7) by hand.
2. Unscrew and remove EARV nozzle (8) by hand.
3. Unscrew nozzle insert (9) from nozzle (8) using air nozzle spanner (10).
4. Clean the spray gun front carefully with damp cloth.
Mount nozzle
– Flat jet
1. Screw in and slightly tighten AF 5000 at jet nozzle (5) by hand.
2. Put the AF 5000 air cap (4) in place. Screw the union nut (1) onto the spray gun body.
3. Set the desired at jet level with the air cap horns (6) and then slightly tighten
the union nut by hand.
– AWR 5000 – round jet
1. Screw on and slightly tighten AWR 5000 nozzle (3) by hand.
2. Position AR 5000 air cap (2). Screw the union nut (1) onto the spray gun body and
slightly tighten by hand.
– EAWRV 5000 – round jet
1. Screw on EAWRV nozzle insert (9) into nozzle (8) using air nozzle spanner (10).
Nozzle insert and nozzle body must be ush, subsequently do not continue turning.
2. Screw on and slightly tighten EARV nozzle (8) by hand.
3. Select EARV union nut (7) depending on the viscosity: HV or LV. Screw the union
nut onto the spray gun body and slightly tighten by hand.
7.4.6 CLEANING OF THE NOZZLE PARTS
The nozzle parts (2, 3, 4, 5, 6, 8 and 9) may only be immersed into a cleaning solvent
recommended by the lacquer manufacturer and must be removed again immediately.
They may only remain in a cleaning solvent for a short time.
Clean these parts with a brush and dry them with a cloth or a blow gun.
