Je bekijkt pagina 4 van 136
4
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
5.6 Operating Elements 33
5.6.1 VM 5020W Control Unit 33
5.6.2 Product Pressure Generator 37
5.7 GM 5020EAW Spray Gun 38
5.7.1 Components 38
5.7.2 Mode of Operation 39
5.7.3 Spraying Procedure for Round Jet Air Atomizing 41
5.7.4 Spraying Procedure for Flat Jet Air Atomizing 42
5.7.5 The Electrostatic Eect 42
6 ASSEMBLY AND COMMISSIONING 43
6.1 Training of Assembly/Commissioning Sta 43
6.2 Storage and Installation Conditions 43
6.3 Transportation 43
6.4 Assembly and Installation 44
6.4.1 Assembling the AquaCoat System 44
6.4.2 Ventilation of the Spray Booth 46
6.4.3 Pneumatic Connections 46
6.4.4 Product Connections 46
6.5 Grounding 47
6.6 Safety Checks 48
6.7 Preparation of Water-based Lacquer 49
6.7.1 Viscosity Conversion Table 49
6.8 Commissioning 50
6.8.1 Preparation 50
6.8.2 Commissioning 50
6.8.3 Verifying a Safe Operational Condition 51
7 OPERATION 52
7.1 Training the Operating Sta 52
7.2 Electrical Discharge 52
7.3 Emergency Deactivation 53
7.4 Working 54
7.4.1 Checking the Spray Pattern (Without Electrostatics) 54
7.4.2 Starting the System 56
7.4.3 Spraying 57
7.4.4 Pressure Relief/Work Interruption 58
7.4.5 Changing the Nozzle, Changing from Round Jet/Flat Jet 58
7.4.6 Cleaning of the Nozzle Parts 59
7.4.7 Starting up the VM 5020W Control Unit 60
7.4.8 Set and Save Recipes 60
7.4.9 Setting the High Voltage 61
7.4.10 Setting the Current Limitation 62
7.4.11 Display during Spraying Mode 63
7.4.12 Standby Mode 63
7.4.13 Operating Hours Counter/Service Display 64
7.5 Device Conguration 66
7.5.1 Overview of Parameters 66
7.5.2 Access to the Device Conguration Mode 67
7.5.3 Setting Example: "Parameter C13" 69
7.6 External Interface 70
