OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
Spare parts list for GM 5000EA adapter
Order No. Description
1 1 -- Adapter, complete GM 5000EA
2
1 2309391 Air manifold ring, Air
3
1 2307180 O-ring, sheathed
4
1 2312176 Valve seat Air, complete (PEEK)
1 2312179 Valve seat Air, complete (steel)
5
1 2312187 Valve tip EAW, complete (PEEK)
1 2312188 Valve tip EAW, complete (steel)
6 1 2314271 Adapter, GM 5000EA, including pos. 2 and 3
7
1 9974166 O-ring
8
1 2311562 Rod seal
9 1 2307062 Clamping screw valve rod
10 1 2312177 Valve rod unit, Air
11
1 2357106 Packing, complete
12 1 2309346 Plug
14 1 2307059 Withdrawal nut
15 1 9901411 Threaded pin with hexagon socket
16 1 2357665 Clamping screw valve rod, complete
17 1 2325263 Clamping screw assembly tool
1 2326391 Service set, GM 5000EAW / GM 5020EAW
= Wearing parts
= Included in service set
= Not part of the standard equipment but available as a special accessory.
