121
OPERATING MANUAL
VERSION 02/2018 ORDER NUMBER DOC 2366717
ZIP52 set spare parts list for AquaCoat
Order No. Designation
1 1 2363856 ZIP52 set for AquaCoat
Double diaphragm pump
2 1 U552.GHSS7
DDP ZIP52 GHSS7
Refer to pump's operating manual for details
3 4 9900108 Hexagon screw without shaft
4 8 9920103 Washer
5 4 9921502 Spring washer
6 4 9910102 Hexagon nut
7 1 353530 Mounting plate
8 1 3304972 Connector female, 6463-10-1/4
Mount on pump support
11 4 3061695 Hexagon screw without shaft
12 8 9920103 Washer
13 4 9910204 Self-locking hexagon nut
Product outlet
21 1 2331062 Fitting, DF-MM-G1/2-G1/4-530 bar-SSt
22
1 2333833 HP hose, complete
23 1 2331971 Fitting, SF-FM-G3/8-G1/4-530 bar-SSt
24 1 T0170.00BI
MPR 40/0.5-8 bar pneumatic SSt
Refer to product pressure regulator's operating
manual for details
25 1 9907019 Screw plug
26 1 9992757 Male stud elbow, 8-1/8
27 1 B0461.03A Fitting, DF-MM-R1/4-1/4NPSM-350 bar-SSt
28 1 2364712 Fitting, RF-FM-NPS1/4-G1/4-530 bar-SSt
29
1 2334488 Ball valve R1/4"-G1/4"-PN530-SSt
30
1 2331752 Return tube, DN6-G1/4"-100mm-PA
31 2 9907001 Hexagon socket cylinder head screw
Product inlet
41 1 2329560 Fitting, DF-MM-R1/2"-M36-PN15-SSt
42 1 2329898 Sealing sleeve
43
1 2324110 Suction hose, complete DN16-SSt
44
1 2323396 Suction lter, DN16-18mesh-SSt
Mounting materials
50 1 9992616 Molykote® DX grease
51 1 9992831 Loctite® 542
Wearing parts
