Je bekijkt pagina 4 van 160
4
OPERATING MANUAL
EDITION 02/2016 ORDER NUMBER DOC 2366600
Table of Contents
5.6 Controls 32
5.6.1 VM 5020W Control Unit 32
5.6.1.1 Operating Elements, Front Side 32
5.6.1.2 Connections on the Rear Side 35
5.6.2 Product Pressure Generator 36
5.6.2.1 Puma 28-40 PE+TG Pneumatic Piston Pump 36
5.6.2.2 Cobra 40-10 Double Diaphragm Pump 37
5.6.2.3 EvoMotion 20-30 Piston Pump 38
5.6.2.4 Working in Accordance with Pump's Operating Manual 38
5.6.3 GM 5020EACW Spray Gun 39
5.6.3.1 Securing the Spray Gun Against Actuation 40
5.6.3.2 Functioning of the Spray Gun 40
5.6.3.3 Spraying Procedure for AirCoat Round Spray 42
5.6.3.4 Spraying Procedure for AirCoat Fan Spray 42
5.6.3.5 Electrostatic E ect 43
6 ASSEMBLY AND COMMISSIONING 44
6.1 Training Assembly/Commissioning Sta 44
6.2 Storage Conditions 44
6.3 Installation Conditions 44
6.4 Transportation 45
6.5 Assembly and Installation 45
6.5.1 Assembling the AquaCoat System 46
6.5.2 Ventilation of the Spray Booth 48
6.5.3 Air Supply 48
6.5.4 Product Supply 49
6.6 Grounding 50
6.7 Safety Checks 52
6.8 Preparation of Water-Based Lacquer 52
6.8.1 Viscosity Conversion Table 52
6.9 Commissioning 53
6.9.1 Safety Instructions 53
6.9.2 Preparation 53
6.9.3 Commissioning 54
6.9.3.1 AquaCoat with Puma 28-40 or EvoMotion 20-30 54
6.9.3.2 AquaCoat with Cobra 40-10 Double Diaphragm Pump 56
6.9.4 Verifying a Safe Operational Condition 57
7 OPERATION 58
7.1 Training the Operating Sta 58
7.2 Safety Instructions 58
7.2.1 Emergency Deactivation for Puma 59
7.2.2 Emergency Deactivation for Cobra 60
7.2.3 Emergency Deactivation for EvoMotion 61
7.2.4 General Rules for Making Adjustments to the Spray Gun 62
7.2.4.1 Electrical Discharge 63
