Technical Manual
WDGA with CANopen Interface
8 - Setting-up the encoder
© Wachendorff Automation GmbH & Co. KG
62
Step 2: Re-mapping the PDO
Mapping of the position value: (No.:1 (Size 32 bit = 20h) into object 1A00h sub-index
1 for PDO1):
600h+ID
8
23h
00h
1Ah
01h
20h
00h
04h
60h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.57: Mapping position value
The SDO command contains the object to be mapped and its size (object 6004h, sub-
index 0, Size 20h = 4 Byte).
Mapping of speed value (No.:2 (Size 16 bit = 10h) into object 1A00h sub-index 2 for
PDO1):
600h+ID
8
23h
00h
1Ah
02h
10h
01h
30h
60h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.58: Mapping speed value
The SDO command contains the object to be mapped and its size: (Object 6030h, sub-
index 1, Size 10h = 2 Byte).
Mapping of acceleration value (No.:3 (Size 16 bit = 10h) into object 1A00h sub-index
3 for PDO1):
600h+ID
8
23h
00h
1Ah
03h
10h
01h
40h
60h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.59: Mapping acceleration value
The SDO command contains the object to be mapped and its size: (Object 6040h, sub-
index 1, Size 10h = 2 Byte).
Step 3: Activating the new mapping
To activate the new mapping, the new number of mapped objects must be written into
sub-index 0 of the mapping parameter object. In our example three objects are
mapped, therefor sub-index 0 has to be set to 03h.:
600h+ID
8
2Fh
00h
1Ah
00h
03h
00h
00h
00h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.60: Mapping parameter – activate new mapping
The re-mapping of PDO1 is now completed and valid, but it should be saved into the
EEPROM (see 8.12).
