Technical Manual
WDGA with CANopen Interface
8 - Setting-up the encoder
© Wachendorff Automation GmbH & Co. KG
59
8.5.2 Synchronous PDO
A PDO can be configured for synchronous transmission, i.e. to respond on a SYNC
message. The sub index 2 of the transmission type parameter determines after which
number of SYNCs received the PDO will be transmitted. (e.g.: If set to 05h, the device
transmits only on every 5. SYNC). Here PDO1 is configured 01h in 1800h-02h:
600h+ID
8
2Fh
00h
18h
02h
01h
00h
00h
00h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.49: Parametrization of PDO1 Sub-Index 2
Therefore transmission type for PDO1 is now synchronous. In Operational state the
PDO1 will be sent as a response on every SYNC message received.
8.5.3 Asynchronous PDO
Cyclic (triggered by internal event timer):
PDOs can be configured for asynchronous cyclic transmission.
Therefor the transmission type in object 1800h-02h (respectively 1801h-02h,
1802h-02h, 1803h-02h) has to be set to FFh. Sub index 5 of the same object is the
cycle time in milliseconds.
Example: PDO1 transmitting asynchronously cyclic:
600h+ID
8
2Fh
00h
18h
02h
FFh
00h
00h
00h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.50: Parametrization of PDO1 Sub-Index 2
Example: PDO1 with a cycle time of 30 milliseconds (1Eh):
600h+ID
8
2Bh
00h
18h
05h
1Eh
00h
00h
00h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.51: Parametrization of PDO1 Sub-Index 5 to 30ms
PDO1 is now in asynchronous mode and will be sent every 30 milliseconds when the
encoder is in Operational state.
