Technical Manual
WDGA with IO-Link
4 - IO-Link
© Wachendorff Automation GmbH & Co. KG
13
4 IO-Link
4.1 Overview of functions
Our IO-Link encoders support the functions shown in Table 4.1 :
Functions
Meaning
Specification
V1.1.4
Baudrate
COM3 (230,4kBit/s)
Profile
SSP 4.2.1: Measuring and Switching
Sensor, high resolution, 1 channel
SSP 4.2.2: Measuring and Switching
Sensor, high resolution, 2 channel
64-Bit Profil
Table 4.1: Functions
4.2 IO Device Description
The available IODDs for the corresponding profiles are listed in Table 4.2:
Functions
Meaning
Wachendorff-Encoder-SSP421-xxx.xml
If profile 4.2.1 is set in the device, this
IODD must be used
Wachendorff-Encoder-SSP422-xxx.xml
If profile 4.2.2 is set in the device, this
IODD must be used
Wachendorff-Encoder-64Bit-xxx.xml
If the 64-bit profile is set in the device,
this IODD must be used
Table 4.2: IODDs
4.3 Standard parameters
4.3.1 Standard parameter identification
Parameter
Index
Subindex
Vendor Name
0x10
0
Vendor Text
0x11
0
Product Name
0x12
0
Product ID
0x13
0
Product Text
0x14
0
Serial Number
0x15
0
HW Revision
0x16
0
FW Revision
0x17
0
Application specific tag
0x18
0
Function Tag
0x19
0
Location Tag
0x20
0
Table 4.3: Identification parameters
