Technical Manual
WDGA with EtherNet/IP
4 - EtherNet/IP
© Wachendorff Automation GmbH & Co. KG
31
individual polarities of the cam
positions can be changed. Thus,
for a value of 13h (= 0110
0100b), CAM 3, CAM 6 and
CAM 7 are inverted when
position value within limits.
See 4.4.2.3
116
CAM low limits 1
LINT
RW
The CAM low limit defines the
lower switching point of a cam
switch position. Each individual
cam position has its own CAM
low limit attribute.
See 4.4.2.4
117
CAM low limits 2
LINT
RW
See above
118
CAM low limits 3
LINT
RW
See above
119
CAM low limits 4
LINT
RW
See above
120
CAM low limits 5
LINT
RW
See above
121
CAM low limits 6
LINT
RW
See above
122
CAM low limits 7
LINT
RW
See above
123
CAM low limits 8
LINT
RW
See above
124
CAM high limits 1
LINT
RW
The CAM high limit defines the
upper switching point of a cam
switch position. Each individual
cam position has its own high
limit attribute.
See 4.4.2.5
125
CAM high limits 2
LINT
RW
See above
126
CAM high limits 3
LINT
RW
See above
127
CAM high limits 4
LINT
RW
See above
128
CAM high limits 5
LINT
RW
See above
129
CAM high limits 6
LINT
RW
See above
130
CAM high limits 7
LINT
RW
See above
131
CAM high limits 8
LINT
RW
See above
132
CAM hysteresis 1
UINT
RW
The width of the hysteresis of the
switchover points is defined via
the CAM hysteresis. For each
individual cam switch position a
separate CAM hysteresis can be
set.
See 4.4.2.6
133
CAM hysteresis 2
UINT
RW
See above
134
CAM hysteresis 3
UINT
RW
See above
135
CAM hysteresis 4
UINT
RW
See above
136
CAM hysteresis 5
UINT
RW
See above
137
CAM hysteresis 6
UINT
RW
See above
138
CAM hysteresis 7
UINT
RW
See above
139
CAM hysteresis 8
UINT
RW
See above
140
Preset execute
BOOL
RW
If the preset value has been set
once in attribute 19, then you
can execute the preset again via
