Technical Manual
WDGA with EtherNet/IP
4 - EtherNet/IP
© Wachendorff Automation GmbH & Co. KG
23
16
TMR
17
TMR
18
TMR
19
TMR MSB
20
Gear Ratio Multiplier LSB
Here the size of
the encoder
gear is set.
21
Gear Ratio Multiplier MSB
22
Gear Ratio Divisor LSB
Here the size of
the main gear is
set.
23
Gear Ratio Divisor MSB
24
Velocity Format LSB
Sets the format
of the position
value.
1F04h: Counts
per second
(default).
1F05h: Counts
per ms
1F07h: Counts
per minute
1F0Fh:
Revolutions per
minute
25
Velocity Format MSB
26
Direction
Counting
Toggle
Scaling
enable
Preset
execute
x
x
x
x
x
Bit 0: Direction
counting toggle
defines the
counting
direction of the
position value.
Bit 1: Scaling
enable
determines
whether scaling
is on or off.
Bit 2: Preset
execute defines
whether a
preset is
executed or not.
27
reserved
Table 4.9: Config Assembly 110
