Technical Manual
WDGA with EtherNet/IP
3 - Device description
© Wachendorff Automation GmbH & Co. KG
12
3.5 LEDs and signalling
Four status LEDs on the bus cover signal the various encoder states and thus support
error diagnosis and troubleshooting in the field (see Table 3.2). The two Link Activity
LEDs (L/A) light up or flash green when the encoder is connected to another Ethernet
node (PLC, switch, additional field device...) and data is being exchanged. The MOD
LED the status of the encoder.
• ATTENTION! The STAT LED is lit during operation but is
negligible for the network status of the encoder.
STAT LED
bicolour
MOD LED
bicolour
Meaning
Cause
No power
Standby
The device has not yet
been fully configured.
Operational
The device has been fully
commissioned and data
exchange is taking place.
/
Self-test
The device is currently
performing powerup
testing.
Major recoverable fault
The device has detected
a major recoverable fault.
(Please contact support)
Major unrecoverable fault
The device has detected
a major unrecoverable
fault. (Please contact
support)
Table 3.2: LED signal
Explanation of symbols and asterisks:
LED off / LED on / LED flashing
