Technical Manual
WDGA with EtherNet/IP
3 - Device description
© Wachendorff Automation GmbH & Co. KG
9
3.3.5 Scaling
To ensure that the position value exactly matches the variables to be physically
measured, an adjustment can be carried out via the scaling parameters. The scalable
parameters are "Measuring units per revolution (MUPR)" and "Total measuring range
in measuring units (TMR)".
The scaling parameter "Measuring units per revolution (MUPR)" — increments per
revolution — indicates the resolution of the position value per revolution (also:
ST-resolution). The value corresponds to 360°. That is, if a value of 3600 Cts is
parametrized, the encoder outputs the position in 0.1° steps (see equation (2)).
𝑀𝑈𝑃𝑅 = 𝑆𝑇 = 3600 𝐶𝑡𝑠
(1)
𝐴𝑛𝑔𝑢𝑙𝑎𝑟 𝑠𝑡𝑒𝑝𝑠 =
𝐴𝑛𝑔𝑙𝑒 𝑜𝑓 𝑜𝑛𝑒 𝑟𝑒𝑣𝑜𝑙𝑢𝑡𝑖𝑜𝑛
𝑀𝑈𝑃𝑅
=
360°
3600 𝐶𝑡𝑠
= 0,1°/𝐶𝑡𝑠
(2)
