Technical Manual
WDGA with CANopen Interface
8 - Setting-up the encoder
© Wachendorff Automation GmbH & Co. KG
54
Within this segment it is indicated that this was the last data segment and that only the
first data byte contained valid data.
The encoder confirms:
580h+ID
8
20h
00100000b
scs=1, t=1
data
x
x
x
x
x
x
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.32: Acknowledgement send by the encoder
The 7 data bytes of the first segment and the single valid data byte of the data bytes
represent the 8 byte "High Precision Position Preset Value" (object 6009h).
8.3.3 Baudrate selection
The encoders WDGA by Wachendorff Automation provide an automatic baudrate
detection. It is also possible to use a fixed baudrate which can be set by either LSS (as
described above) or SDO.
The configuration of the encoder is only possible in Pre-Operational mode. To alter the
baudrate you have to change the object 2100h into Sub-Index 00h. This can be
achieved with a simple SDO write command with the target baudrate as data.
600h+ID
8
2Fh
00h
21h
00h
Baud
00h
00h
00h
CAN-ID
DLC
Command
Object
L
Object
H
Sub-
Index
Byte0
Byte1
Byte2
Byte3
Table 8.33: SDO command – set baudrate
The following values represent the valid baud rates:
Value
Baudrate
0
1 Mbit/s
1
800 kBit/s
2
500 kBit/s
3
250 kBit/s
4
125 kBit/s
5
100 kBit/s
6
50 kBit/s
7
20 kBit/s
8
10 kBit/s
9
Auto
Table 8.34: Baudrate-coding
