- 5 -
NOTE: In the Commonwealth of Massachusetts
All gas appliances vented through a ventilation hood or exhaust system equipped with
a damper or with a power means of exhaust shall comply with 248 CMR.
3. NFPA Standard # 96 Vapor Removal from Cooking Equipment, latest edition, available
from the National Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
In Canada:
1. Local codes.
2. CAN/CSA-B149.1 Natural Gas Installation (latest edition)
3. CAN/CSA-B149.2 Propane Installation Code (latest edition), available from the
Canadian Gas Association, 178 Rexdale Blvd., Etobicoke, Ontario, Canada M9W
1R3
LEG INSTALLATION
The stockpot range is shipped without the legs attached. The
stockpot range must not be operated without the legs attached to the unit.
1. Remove cast iron grate and burners from chassis.
2. Turn chassis upside down and locate threaded leg weldments (Fig. 1).
3. Screw legs into threaded leg weldments until tight (Fig. 2). Use a pipe or strap wrench
with a towel (so as not to scratch leg) if needed to firmly tighten legs.
4. Continue process until all legs are installed. Single stockpots will have four legs
and double stockpots will have six legs.
5. Return stockpot to upright position; reinstall burners and grates.
THREADED LEG
WELDMENT
LEG
Fig. 1
Fig. 2
