GENERAL
INSTALLATION, OPERATION AND
CLEANING
Refer to the Installation & Operation Manual for
specific instructions.
INTRODUCTION
Features
• Requires no water or drain line connections
(manual fill & manual drain).
• Cast aluminum element block for efficient heat
transfer and distribution.
• Field convertible to single phase or three phase
power depending on the supply available.
• 3.0 gallons maximum holding pan capacity.
Steam Cooking
The C24EO series steamer provides timed or
continuous mode cooking in a pressure-less
compartment. The small physical size of the steamer
offers an efficient way to produce many foods in small
batches. Pressure-less, convection steam cooking will
steam cook fresh foods or will steam defrost and cook
frozen foods providing the maximum color, flavor and
nutritional value with the least expenditure of energy
and labor. The pressureless cooking compartment
allows the operator to open and close the door,
anytime during a cooking cycle.
Model Designations
• C24EO3 - 3 pan capacity
• C24EO5 - 5 pan capacity
NOTE: based on 2.5 inch pan depth
Exterior Dimensions
• C24EO3 - 24" w x 33" d x 19.5" h
• C24EO5 - 24" w x 33" d x 26" h
SPECIFICATIONS
A potable water supply does not guarantee that it's
suitable for steam generation. The water supply must
be within the following specifications or a local water
treatment specialist may need to be consulted. If a
water treatment system is installed, it must be properly
maintained.
WATER REQUIREMENTS
• Hardness - Less than 3 grains (17.1ppm = 1 grain
of hardness)
• Silica - Less than 13 ppm
• Total Chloride - Less than 4 ppm
• Ph range of - 7.0 to 8.0
• Un-dissolved Solids - less then 5 microns
ELECTRIC
MODEL
TOTAL
KW
AMPERAGE PER LINE
3 PHASE 1 PHASE
208
V
240V 480V 208V 240V
C24EO3 8 22.2 19.2 - 38.5 33.3
C24E05 12 33.3 28.9 14.4 57.5 50.0
NOTES:
1. Amperage values in the table are
nominal. Tolerance is +5/-10%.
2. C24EO3 - Shipped for 208V 60-50
HZ 3 phase connection. Field
convertible to 240V three phase or
208/240V single phase. See wiring
diagram AI2853.
3. C24EO5 - Shipped for 208V or 240V
or 480V 60-50 HZ, 3 phase. 208V
and 240V models are field
convertible to 1 phase. See wiring
diagram (LINK to AI2852).
TOOLS
C24EO SERIES ELECTRIC COUNTERTOP STEAMERS - GENERAL
F25386 Rev. C (0421) Page 6 of 43
