7
EN
Install Instruction
Door Right-Left Change
List of tools to be provided by the user
Cross screwdriver
Thin-blade screwdriver
Masking tape
5/16’’ socket spanner
1. Fix the door by tapes.
2. Dismantle hole caps, the upper hinge
cover, fitting screws of upper hinge, and
remove the upper hinge, please keep the
door vertical in whole process for avoiding
falling down.
Upper hinge cover
Upper hinge
Screw hole cap
3. Remove the door. dismantle the stopper
under the door,then assemble the stopper
on the other side.
4. Remove the lower hinge assembly and
levelling foot.
Lower
hinge assembly
Leveling foot
5. Install the lower hinge and levelling foot on
lower left side of cabinet and lower right
side respectively.
Lower hinge assembly
Leveling foot
6. Put the door on lower hinge vertically, and
validate the gas tightness of door gasket,
then install the upper hinge by fitting
screws and the hinge cover, finally cover
the hole caps on upper right side.
The picture above is only for reference. The actual
configuration will depend on the physical product
or statement by the distributor
