10 English
Using a phillips head screwdriver, re-
move grille by unscrewing the 4 screws
located along the perimeter of the inlet
grille at roughly 2, 5, 7, and 11 o’clock
positions. This will release the grille. To
reattach, position grille so the logo in
the center of the grille is straight. Models
5303, 6303, 6803, 7503, 7803, align the
Locator Pin (A) to reconnect grille. Once
aligned replace screws.
Model 1303, align the Alignment Rib (B)
to reconnect grille. Once aligned replace
screws.
CLEANING
GRILLE REMOVAL Screwdriver required.
WARNING: To reduce the risk of electrical shock and injury to persons, unplug the circulator before removing grille.
Use the brush attachment on your
household vacuum cleaner to
vacuum any accumulated dust off
the Front Grille and Air Inlets.
Note: The motor is
permanently lubricated
and requires no oiling.
²
²
²
²
A
B
