10
EN
WWW.VONROC.COM
Before assembly, always switch off the
machine and remove the battery
Mounting and removing accessories (Fig. A, B)
Make sure to use the right accessory for the
corresponding material. Use undamaged and clean
polishing accessories only.
Backing plate
1. Place the machine on its back.
2. Put the hex key (8) in the backing plate hex
screw (7).
3. Hold the backingplate (6) with one hand to keep
it from rotating.
4. Unscrew the backingplate hex screw (7) using
the hex key (8).
Polishing pad
1. Place the machine on its back.
2. Firmly press the polishing pad onto the hook
and loop backingplate (6).
To remove the polishing pad, simply pull the pad
from the backingplate (6).
4. OPERATION
The battery must be charged before first
use.
Wear protective gloves when changing the
tool so as to avoid injuries frum cuts.
Caution! The Backing plate (6) still runs for
some time when the machine is turned off.
Switching on and off (Fig. A)
The on/off switch (2) is used for activating the
machine
• To switch on the machine, press the on/off
switch (2).
• To switch off the machine, release the on/off
switch (2).
Locking the switch in to safety (Fig. A)
Press the safety lock button (3) to keep the switch
from being pressed.
Locking the switch in the on position (Fig. A)
Lock the switch into the on postion by pressing the
lock-on button (4)
Speed control (Fig. B)
The speed of the disc can be controlled with the
variable speed switch on top of the handle. The
higher the position, the higher the speed. The
variable speed switch can be set to 7 positions.
When used for sanding the ideal speed depends
on the required grain size and on the material to be
worked. When using wax on the polishing pad do
not start at a high speed.
Do not set the speed during use.
Hints for optimum use during polishing
• Always make sure the machine if properly
cleaned before use to prevent scratches during
polishing.
• For best results, the surface should be clean
and dry.
• Do not apply polish directly to workpiece.
Apply a small amount of polish on the polishing
bonnet.
• Begin by polishing larger flat surfaces. Use a
sweeping motion in a criss-cross pattern.
• Once flat surfaces have been covered, polish
curved surfaces.
• For hard to reach areas, apply polish by hand.
• Do not use any type of abrasive cleanser as it
may damage or scratch the surface.
WARRANTY
VONROC products are developed to the highest
quality standards and are guaranteed free of
defects in both materials and workmanship for the
period lawfully stipulated starting from the date of
original purchase. Should the product develop any
failure during this period due to defective material
and/or workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the machine by unauthorized
service centers;
• Normal wear and tear;
• The tool has been abused, misused or
improperly maintained;
• Non-original spare parts have been used.
