Je bekijkt pagina 6 van 52
6
EN
WWW.VONROC.COM
is heavily loaded.
• Do not sit on the sides of the hand cart, as this
may cause it to tip over.
2. MACHINE INFORMATION
Intended use
This hand cart has been designed for the trans-
portation of loads up to the maximum weight and
to be folded for easy storage. The hand cart is
not suitable for transport of people or loads that
cannot be securely attached. It is not to be used for
commercial or industrial purposes.
TECHNICAL SPECIFICATIONS
Model No. HC503XX_BLACK
Max load capacity 120 kg
Frame material Steel
Fabric material Polyester 600D
Dimensions (folded) 610x200x730mm
Dimensions (unfolded) 950x600x1050mm
DESCRIPTION
The numbers in the text refer to the diagrams on
pages 2-4.
1. Handle
2. Frame
3. Storage bag
4. Side panel
5. Cup holder
6. Wheel
7. Sidepanel zipper
8. Handle height adjustment knobs
9. Brake lock
10. Brake unlock
11. Loop for folding and unfolding
12. Inner lining
13. Transport handle
14. Foldable side panel
15. Foldable side panel zipper
16. Buckle
3. OPERATION
Unfolding for usage (Fig. A, B1, B2, B3, B4, B5)
1. Remove the storage bag (3)
2. Press down on the loop for folding and
unfolding (11)
3. Unzip the side panel zipper (7)
4. Put in the inner lining (12)
5. Adjust the handle (1) to the desired length.
Engaging the brakes. (Fig. C1 and C2)
1. Press the brake lock (9) on both wheels to
engage the brakes.
Disengaging the brakes. (Fig. C1 and C2)
1. Press the brake unlock (10) on both wheels to
disengage the brakes.
Unfolding the foldable side panel (Fig. A, E)
Make sure the brakes are engaged before
unfloding the foldable side panel (14).
Never unfold the foldable sidepanel on
unleveled ground surfaces/ inclines or
unstable ground.
1. Make sure the hand cart is positioned on a le-
veled and stable surface and engage the brakes
by pressing in the brake lock (9).
2. Unzip the foldable side panel zipper (15). and
undo the buckle (16).
3. Fold the flap over to the inside of the cart (as
shown in Fig. E.
Folding for storage (Fig. A, B1, B2, B3, B4, B5)
1. Make sure the handle (1) is in the lowest
position.
2. Unzip the sidepanel zipper (7). Remove the
Inner lining (12).
3. Bind the transport handle (13) together with the
hooks and loops on the transport handle (13)
4. MAINTENANCE
Risk of damage! Improper handlining of the
hand cart can lead to damages. Always
check product for damage before first use.
Check regularly that the hand cart is in perfect con-
dition, re-tighten the screws if necessary and make
sure the frame engages correctly.
Clean the product
• Never use mineral spirits, solvents or aggres-
sive cleaning agents for cleaning.
• Clean the product with adamp cloth and , if
necessary, with amild detergent.
