1. SAFETY INSTRUCTIONS
Read the enclosed safety warnings, the additional
safety warnings and the instructions. Failure to
follow the safety warnings and the instructions may
result in electric shock, fi re and/or serious injury.
Save the safety warnings and the instructions for
future reference.
The following symbols are used in the user manual
or on the product:
Read the user manual.
Risk of personal injury.
Not intended for use by children.
Protect the automatic hose reel against
frost.
The product is in accordance with the
applicable safety standards in the European
directives.
SAFETY WARNINGS
THIS APPLIANCE CAN BE USED BY CHILDREN
AGED FROM 8 YEARS AND ABOVE AND PERSONS
WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES OR LACK OF EXPERIENCE
AND KNOWLEDGE IF THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE OF
THE APPLIANCE IN A SAFE WAY AND UNDERSTAND
THE HAZARDS INVOLVED. CHILDREN SHALL NOT
PLAY WITH THE APPLIANCE. CLEANING AND USER
MAIN- TENANCE SHALL NOT BE MADE BY CHILDREN
WITHOUT SUPERVISION.
Please read these instructions carefully and
thoroughly before using this appliance and keep
them for future reference. It is very important that
you understand how to use this appliance safely so
please take the time to familiarize yourself with the
requirements as outlined in these instructions.
• If you are in any doubt what so ever about using
this appliance, we strongly recommend that
you employ the services of a suitably qualifi ed
person.
• Physical injury through prestressed springs. The
Hose Box may not be opened.
• Keep children and pets well away from the
work area and never allow children to use this
appliance at any time.
• When not in use, keep this appliance stored in a
safe place out of reach of children.
• Never leave the appliance unattended when in
use.
• Using air pressure must not be higher than 17
Bar / 245 PSI to avoid the damage of product.
• Hold the hose stopper (8) when the hose is
retracting and follow the retraction until it
fi nishes.
• Not intended for professional use
• Only usage is for transporting compressed air, no
liquids or other gases allowed.
2. MACHINE INFORMATION
Model No. AH503XX
Hose length 15m
Max. inlet pressure 17 bar / 245 PSI
Outside hose diameter 14,5 mm
Inside hose diameter 9,2 mm
DESCRIPTION
The numbers in the text refer to the diagrams on
page 2-3.
1. Hose box
2. Wall bracket
3. Rotating shaft
4. Output connector
5. Input connector
6. Wall plug
7. Screw bolt
8. Adjustable Hose Stopper
3. ASSEMBLY
Mounting the wall bracket (Fig. A, B)
The most appropriate position is to mount it on a
wall, no more than 1 meter above the ground.
1. Drill 4 holes in the wall with as shown on fi gure
B1.
2. Place the plugs (6) in the drill holes.
3. Align the holes of the bracket (2) in front of the
plugs (6).
4. Screw bolt (7) through the bracket into the wall/
plugs (6).
