Je bekijkt pagina 9 van 38
6
1 Fan Do not block the outlet of the fan
, otherwise the
internal heat dissipation of the machine will lead to
excessive internal temperature.
2 Remote
compensation
When the remote sensing function is enabled, this
sampling terminal should be connected to the load
side to compensate for the voltage drop across the
wires. After enabling the function, please ensure that
Vsen+ is connected to the output positive (+), and
Vsen- is connected to the output negative (-). Do not
reverse the connections or leave them floating.
3 DB9 interface
This port includes RS232 and RS485 function, user
can use RS232 for communication control, and
RS485 can be used as multi-
machines parallel
function.
4
AC power Input
sticker
Indicate AC power input 230 V/AC.
5
USB(VCP) serial
port
This USB(VCP) serial port can be used to connect to
a computer.
6 Trig The Trigger In/Out function allow e
xternal trigger
signal input and output.
7 AC Power
terminal
The power supply line inputs AC power, from this
connection terminal to the input terminal.
