please confirm that the front panel input terminals are correctly connected to
the device under test. It can be released by pressing the power button or the
ENTER button.
Fault Type
ERROR CODE
Fault cause Description
MAINS AC
FAULT
0x0002
Abnormal mains undervoltage
INTERNAL
FAULT
0x0004
Over temperature protection
0x0010
Error in internal parameter storage
0x0020
Model firmware match error
OUTPUT
FAULTS
0x0002
Output over voltage protection
0x0008
Output over current protection
0x0010
Output over power protection
0x0004
Local Reverse Voltage Protection
PARALLEL
FAULTS
0x0001
Parallel address conflict
0x0002
Multiple master fault
0x0008
Communication drop
0x0010
Mismatch in operable unit fault
4.10 Communication Port Introduction
The rear panel of the load in this series is equipped with a USB serial port.
After connecting to a PC, ensure that the serial port settings in the PC
software interface match those of the load device (9600 baud rate, 8 data bits,
no parity, 1 stop bit).
USB port
Use a USB cable with USB A-type on one end and USB B-type on the other
end to connect the load to the computer. All electronic load functions can be
controlled through USB programming. After connecting the load and PC via
USB, the CH340 USB driver needs to be installed (available for download
from the our website or by directly contacting our technical support), otherwise,
communication will not be successful.
The electronic load supports RS232 and RS485 (for internal parallel use). The
following table provides the corresponding pin definitions (output via DB9
terminal connector):
