Error! Use the Home tab to apply 标题 1 to the text that you want to appear

here..Error! Use the Home tab to apply 标题 1 to the text that you want to appear

here.

33

There are 43 kinds of measurement including:Period, + Width, Rise

Time, +Duty, Frequency, - Width, Fall Time, -Duty, ScrDuty, Vavg, Vpp,

Vamp, StdDev, Vmax, Vtop, VRMS, Overshoot, Vmin, Vbase, CycRms ,

Preshoot, +PulseCnt, -PulseCnt, RiseCnt, FallCnt, Area, CycArea,

Delay(1 -2 ), Delay(1 -2 ), Delay(1 -2 ), Delay(1 -2 ),

Phase(1 -2 ), Phase(1 -2 ), Phase(1 -2 ), Phase(1 -2 ),

FRR(1 -2 ), FRF(1 -2 ), FFR(1 -2 ), FFF(1 -2 ), LRR(1 -2 ),

LRF(1 -2 ), LFR(1 -2 ) and LFF(1 -2 ).

Automatic measurement can not be performed when storing the waveform

or calculating double waveforms. In slow sweep, both the cycle and

frequency can not be measured.

For example: To measure the cycle and +Width of CH1 channel signal,

operate according to the following steps:

1. Press Measure key and the setting window is displayed on the screen.

2. Click the Switch to On state and the circle is highlighted.

3. Click Signal Source CH1 to highlight it.

4. Click Period and +Width in the horizontal measurement, and the circle

is checked and highlighted.

The measured values will be automatically displayed at the lower left of the

screen.
