6 Low Profile Hinged Glass Breath Guards Installation Instructions
SINGLE-SIDED RETROFIT KIT INSTALLATION (CONTINUED)
Remove the Mounting Bracket
1. Remove the inner frame plugs. Save the plugs.
2. Remove the hinge by removing the hinge assembly screws.
Install the Ballast Bar
1. Attach the ballast bar using the included screws.
2. Reinstall the frame plugs.
Install the End Glass
1. Insert the included short-end glass panel into the gasket on the
upright support.
2. Tighten the set screws and install the set screw plugs.
3. Repeat for the other end.
Reinstall the Top Glass
1. Set the top glass into place. Align the holes on the glass with the
holes on the stand-offs. Thread the vinyl washers onto the caps and
insert into the holes. Tighten the caps. Do not over tighten.
End Profile of Single Sided Breath Guard
