PFW 6870

Installation Guide

Installationsanleitung, Guía de Instalacíon, Guida de Installazione, Guide d’Installation, Installatie gids

1. Swipe GAPit along vertical gap

2. Inspect for .050” gap & adjust if

needed

3. Swipe GAPit along horizontal gap

4. Inspect for .050” gap & adjust if

needed

Damage happens when weight is transferred to the ultra-thin bezels of video wall installations,

if the recommended gap specications of .050” is not maintained vertically and horizontally.

This results in image distortion, and costly repairs and replacement

Use the GAPit GO/No Go Gauge (supplied with model specific spacer) as a final step in the process

to inspect and adjust the gap to prevent costly replacement and extend the lifespan of the displays.

20

www.vogels.com | Europe +31 (0)40 26 47 400
