20
Displaying the Group & Frequency
UHF-8900 Frequency List
The module LCD displays all the information regarding the microphone Group (GR) and
Channel (CH). It is important to understand what each icon represents.
• Frequency: This is the frequency that the microphone is currently using. It is easier to
refer to this as a combination of both Group and Channel numbers.
For example: 655.MHz would be GR 2-1 & CH 01.
• Group: The Group number is the subset of frequencies to choose from in each module.
The UHF-8900 displays the module in a few different ways
The top Module row - The groups are listed sequentially starting from GR 01 through
GR 05.
The bottom Module row (Left 2 Modules) - The Groups are listed as GR 1-1 through
G 1-A
The bottom Module row (Right 2 Modules) - The Groups are listed as GR 2-1 through
GR 2-A.
• Channel: This is the number of frequencies in each Group. These are listed the same way
in all modules, CH 01 and up.
Please refer to pg. for a complete list of Groups and Frequencies to choose from.
GR 01 GR 02 GR 03 GR 04 GR 05
CH 01 902.60 906.00 903.75 902.70 905.00
CH 02 906.90 904.40 907.60 904.60 907.75
CH 03 908.05 914.90 909.40 908.20 909.20
CH 04 912.80 917.50 916.00 911.95 911.05
CH 05 914.25 919.10 919.50 914.90 916.15
CH 06 915.95 921.85 921.10 922.75 922.75
CH 07 917.25 924.80 923.55 925.40 923.85
CH 08 925.30 926.80 925.60 927.55 927.70
Used by the top 4 modules
