15
Basic Operations
Status 4.3
The Feather Amp has three LED indicators to help you monitor status and troubleshoot system failures. The Bridge LED
indicates BTL mode, which is a non-critical operational mode; however, the Thermal and Overload LEDs indicate a critical
performance level and require immediate attention. If at any time, either Thermal or Overload protection is triggered, Feather
Amp will either automatically cut its output power or shut down. In the case of a shut down the power supply will rapidly try
to restart if the circuit’s temperature is acceptable.
The Bridge LED will illuminate when BTL mode is enabled. When not in BTL mode, the LED will remain off.
The Thermal LED indicates thermal protection mode has been triggered. This occurs when the amplifier’s
continuous power handling is too high. If this occurs, please refer to the troubleshooting section.
The Overload LED indicates too much current (over 30A) is being received. In order to prevent an accidental
shutdown during peak currents, Overload protection allows for 100ms to 500ms of operation before
automatically shutting down.
Mounting 4.4
The Feather Amp’s mounting plate can be attached to the top or the bottom of its casing. This makes for versatile mounting
options, both interior and exterior.
To change the position of the mounting plate, remove the small fastening screws. Move the plate to the other position and
secure with the screws.
POWER
BRIDGE
STATUS
THERMAL
OVERLOAD
Mp3
LEFT
RIGHT
FA-500
FEATHER AMP FA-500
Top Mounted
Top View
Bottom Mounted
Bottom View
