2
CONTENTS
Listening for a Lifetime .……………………………….……..........................…….……....................................……… 1
Features………………………………………………………………………………………………………………………………….... 2
Specifications ..……………………………………………………………………………………………………......………………... 2
Before Getting Started…..……………………………………………………………………………………………………………… 3
Front Panel Description and Functions……………………………………………………………………………………………. 4-5
Rear Panel Description and Functions.……………………………………………………………………………………………. 6-7
Remote Control Descriptions and Functions………………………………………………………………………….............. 8-9
Advanced Operation.………………………………….………….………….………….………….………….…..............……... 10
Getting Connected.….……………………………………………………………………………………………………….….....11-14
Troubleshooting………………………………………………………………………………………………………………......….. 15
Glossary of Terms…………………………………….………………………………………………………………………………. 16 Other Recommended VocoPro
Gear…………………………………………………………………………………………… 17-18
S
PECIFICATIONS
Mic
Input Sensitivity ......................................................................................................................
Frequency Response ....................................................................................................
Delay Time .............................................................................................................................
Signal to Noise Ratio .....................................................................................................................
Limitation .....................................................................................................................................
Bass ......................................................................................................................................
Treble ....................................................................................................................................
Audio
Input Sensitivity .........................................................................................
Output Voltage ............................................................................................................
Coaxial Input .......................................................................................................................
Bass ...................................................................................................................................
Treble ..................................................................................................................................
Video
Input Voltage .........................................................................................................................
Output Voltage ......................................................................................................................
Dimensions
(W x D x H) ..............................................................................................................
Net Weight ...................................................................................................................................
Gross Weight .................................................................................................................................
DTX-5000G FEATURES:
• CDG+Decoder/Pre-Amp
• 11-Step 32-Bit DSP Key Controller
• 3-Microphone Channels w/XLR and 1/4" Input Jacks
• Professional Digital Echo/Repeat/Delay
• Vocal Eliminator Eliminates or Reduces the Vocals on any CD
• Variable Outputs (Allows Direct Connection to Amp)
• Full-function Remote Control to Operate all Features
• On-Screen Display shows all Remote-Control settings
• 3-Audio/Video Inputs
• 2-Switchable Digital Inputs w/Optical and Coaxial Jacks
• NTSC/PAL for both U.S. and European TVs
• Dimensions : 19-1/4” (L) x 10-1/5” (D) x 5” (H)
4 mV / 10kž
20Hz ~ 18KHz ±4dB
260 ms Max
> - 65dB
> +15dB
100Hz ±8dB
10KHz ±8dB
250 mV / 10kž (AV1-AV2-AV3)
2 Vrms (Audio Out 1)
600 mV (Audio Out 2)
0.5 Vp-p / 75ž
100Hz ± 10dB
10Khz ± 10dB
1 Vp-p / 75ž
1 Vp-p / 75ž
17” W x 7” D x 1.7” H
6.6 Lbs
7.5 Lb
