15
MANUALLY:
1. Press and hold the unlock button the access the Menu.
2. Highlight and select the “GR/CH” option with the Selector Knob.
3. Select from either “GR” or “CH” to modify the channel.
a. GR – Refers to the Group of Channels to choose from. There are 15 Groups.
b. CH – Refers to the Channels within the Groups. There are 6 channels within each Group.
4. Use the Selector Knob to confirm selections.
5. Once confirmed, hold the microphone IR sensor in line and within 4 inches of the IR sensor
located near the display.
6. Press the IR button to communicate the new frequency to the microphone.
NOTE: Each channel is one microphone frequency.
Operations
AF
GR/CH
SCAN
TX PWR
919.10
MHz
01 06
RF
HI
GR CH
AF
GR/CH
SCAN
TX PWR
919.10
MHz
01 06
RF
HI
GR CH
1 5
6 4
4”
AF
GR/CH
SCAN
TX PWR
919.10
MHz
01 06
RF
ÉÑ
GR CH
2
3
AF
GR/CH
919.10
MHz
01 06
RF
ÉÑ
GR CH
GR
CH
