13
CHANGING THE FREQUENCY:
The Digital-1 utilizes a frequency analyzer to provide a graphical view of the environmental
interference. The color LCD screen will display a graph of the current interference. Once identified, the
frequency can be changed automatically or manually.
AUTOMATICALLY:
1. Press and hold unlock button to access the Menu.
2. Highlight and select the “Scan” option with the Selector Knob.
3. Select which half of the spectrum will be scanned, either Up or Down.
4. Use Selector Knob to confirm selection and start Frequency Scan.
5. Once Scan is complete, hold microphone IR sensor in line and within 4 inches of the IR sensor located
near the display.
6. Press the IR button to communicate the new frequency to the microphone.
OPERATIONS
1
5
46
AF
GR/CH
SCAN
TX PWR
919.10
MHz
01 06
RF
HI
GR CH
AF
GR/CH
SCAN
TX PWR
919.10 MHz
01 06
RF
HI
GR CH
2
3
IR
4”
AF
SCAN
UP
DOWN
904.40
MHz
X:902.00Mhz 3Mhz/div
Y:REF - 50 dBm 20 dB/div
RF
HI
