5
Features and Specifications
Amplifier
Power Output ......................................................................................... 100W x2 (RMS 8 Ω, THD 1%)
......................................................................................... 120W x2 (RMS 4 Ω, THD 1%)
Total Harmonic Distortion ................................................................. (8 Ω 10W) 0.1%
S/N Ratio ............................................................................................... 78dB
Pre Music Channel
Input Sensitivity ..................................................................................... 240mV
Over Load Power (1KHz) ................................................................... 3.7V
Sensitivity ................................................................................................ 6mV
Frequency Response ...........................................................................
20 Hz ~ 20 KHz (-3dB ~ +1dB)
Pre
Microphone Channel
Input Sensitivity ..................................................................................... 14mV
Over Load Power (1KHz) ................................................................... 200mV
Frequency Response ........................................................................... 50 Hz ~ 10 KHz (
±1.5dB)
General
Power ....................................................................................................... AC ~ 120V, 60Hz
Max power .............................................................................................. 500W
Dimensions ............................................................................................. 17.1”(L) x 14.1”(W) x 5.2”(H)
Weight ...................................................................................................... 19.2 lbs.
• 300W (RMS) and 600W (MAX) power output
• 3 microphone inputs (¼”) with individual volume controls plus 2 additional ¼” inputs
• DSP vocal Echo with Repeat and Delay controls
• DSP vocal Reverb with Time and Level controls
• 4 programmable custom effects
• Vocal Cancel removes the vocal track on Multiplex formatted CD+G discs
• ± 5-step Digital Key Control
• C-MODE function toggles between Mic-only and Music-only for the Center Out channel
• Connect up to 4 external A/V players (RCA)
• Automatic input selector
• Feedback eliminator with 3 available strength levels
• Master Music and Microphone volume controls
• Music Bass and Treble tone controls
• Vocals Bass and Treble controls
• Master Effect Level control
• Inputs: 4 RCA AV (DVD, CD, CDG, AUX), Digital RS232, 1 External EQ L/R RCA in
• Outputs: 2 L/R banana plug Speaker outs , 1 L/R RCA Record out, 1 RCA video out,
1 L/R Center out, 1 External EQ L/R RCA
out
• Full-function remote control
Features
Specifications
