Front Panel Descriptions
9
15. ECHO DEL. control – This control is also a facet of the Digital Echo process. DELAY adjusts the total
beginning and ending length of each echo interval. As more DELAY is applied to the ECHO effect, each
ECHO interval will become longer in time. Turn clockwise to increase the DELAY level and counter-clockwise
to decrease the DELAY level.
16. INPUT SELECTOR button – Press the button to its inward position to select the device connected to the
CDG channel as the active INPUT SOURCE. Release the button to its outer position to select the device
connected to the DVD channel as the active INPUT SOURCE.
17. MUSIC VOL. control – This control increases/decreases the MUSIC VOLUME level(s) from INPUT
SOURCES that are connected to the CDG/DVD channels. Turn clockwise to increase MUSIC VOLUME and
counter-clockwise to decrease the MUSIC VOLUME.
18. MUSIC LO. control – This control increases/decreases the amount of LOW frequency response applied to
the audio output of INPUT SOURCES connected to the CDG/DVD channels. Turn clockwise to increase the
LOW frequency response and counter- clockwise to decrease the LOW frequency response.
19. MUSIC MID. control – This control increases/decreases the amount of MID-RANGE frequency response
applied to the audio output of INPUT SOURCES connected to the CDG/DVD channels. Turn clockwise to
increase the MID-RANGE frequency response and counter-clockwise to decrease the MID-RANGE
frequency response.
20. MUSIC HI. control – This control increases/decreases the amount of HIGH frequency response applied to the
audio output of INPUT SOURCES connected to the CDG/DVD channels. Turn clockwise to increase the HIGH
frequency response and counter- clockwise to decrease the HIGH frequency response.
PRO
Digital
Echo
BAL.VOL.
GAIN ON
MIC 1
GAIN
ECHO
INPUT
SELECTOR
ON
MIC 2
MIC 3
BAL.
MID. HI
MID.
LO
LO HI
LO HI
LO
-15 +15 -15 +15
-15 +15 -15 +15
-15 +15 -15 +15 -15 +15
-15 +15 -15 +15 -15 +15
0 10
-15 +15 -15 +15
-15 +15
MID. HI
VOL.
ECHO
ECHO
ECHO VOL.
DEL.
VOL.MUSIC MASTER
CHANNEL
BAL.
-15 +15
LO HI
POWER
ON
Digital Karaoke Mixing Amplifier
0 10
0 10
0 10 0 10-5 +5
0 10 0 10-5 +5
0 10
VOL.
MIC 2 / MIC 3
CONTROLS
MIC 3
INPUT
MIC 2
INPUT
MIC 1
INPUT
NORMAL GAIN
NORMAL GAIN
PRO
ECHO
ECHO
DVD CDG
RPT.
0 10
1517 18 19 2016
