CONNECTING OTHER
COMPONENTS TO THE CDG X-3 MARK II
The CDG X-3 Mark II is designed so you can connect other components to it and use the Karaoke features that are built-in to the CDG
X-3 Mark II in conjunction with those components.
EXPANDING YOUR SYSTEM - USING THE CDG X-3 MARK II FEATURES WITH OTHER COMPONENTS
You may use the Karaoke features (echo, delay, key changer) that are built into the CDG X-3 Mark II with other components just by
connecting the components as described in this section. The Karaoke features will automatically be functional when additonal compo-
nents are properly connected. (Also see REAR PANEL PARTS AND FUNCTIONS for additional connection information)
CONNECTING A DVD PLAYER OR MINI-DISC PLAYER
Using and RCA connector cable, connect the “L” and “R” “DVD” INPUT jacks to the “L” and “R” “AUDIO OUTPUT” jacks on the
DVD player (check manufacturer’s instructions). BE SURE TO SET THE INPUT SELECTOR ON THE FRONT OF THE CDG X-3 MARK
II TO “DVD”, OTHERWISE THERE WILL BE NO SOUND. Play the DVD player as usual. Music from the DVD player will be audible
from your speakers and the Karaoke features will be functional.
CONNECTING A LASER DISC PLAYER
Using and RCA connector cable, connect the “L” and “R” “LD” INPUT jacks to the “L” and “R” “AUDIO OUTPUT” jacks on the LD player
(check manufacturer’s instructions). BE SURE TO SET THE INPUT SELECTOR ON THE FRONT OF THE CDG X-3 MARK II TO “LD”,
OTHERWISE THERE WILL BE NO SOUND. Play the LD player as usual. Music from the LD player will be audible from your speakers and
the Karaoke features will be functional.
CONNECTING AN AMPLIFIER (for sound)
An amplifier should be connected to the CDG X-3 Mark II through the “L” and “R” “PRE” OUTPUT jacks located in the back of the CDG
X-3 Mark II (See manufacturer’s instructions with your amplifier)
8
“L” and “R” “PRE” OUTPUT jacks
