15
Basic Operations
Using the MPX/Stereo Switch
The MPX switch will change the Casaman into pseudo-stereo mode, the Left Channel audio being sent through both Left
and Right speakers. It is intended for use with Multiplexed tracks,
songs designed to have the main vocals removed. If used with non-
Multiplexed tracks, it may cause the audio to be unintelligible or sound
improper.
Connecting to a Computer via USB
IF USING A PC:
Playing music to the Casaman.
When connected via USB to the computer, the appropriate drivers
will install automatically and will change the sudio settings required to send the audio to
the Casaman.
Note: These settings revert to normal once the Casaman is disconnected from the computer.
Recording Audio from the Casaman.
- When connected via USB to the computer, any audio (music and microphone signal) played
through the Casaman will stream back to the computer.
- Use a recording program to capture the audio the Casaman is sending to the computer.
IF USING A MAC:
Playing music to the Casaman.
Please refer to your Apple computer manual for detailed instructions regarding audio settings.
- When connected via USB to a MAC, the appropriate sound settings must be altered to select
“USB Audio Codec” as the primary output destination.
- Use a music program to playback tracks and the audio will stream to the Casaman via the USB cable.
Recording Audio from the Casaman.
- When connected via the USB to a MAC, the appropriate sound settings must be altered to select “USB Audio Codec”
as the primary input source.
- Once the settings are changed, any audio (music and microphone) played through the Casaman will stream back to the
computer.
- Use a recording program to capture the audio the Casaman is sending to the computer.
Installing a Stereo Expansion Module
- Locate the stereo expansion port.
- Remove the metal cover plate and locate the 6-pin ribbon cable
inside.
- Firmly press the 6-pin ribbon cable into the 6-pin socket on the
expansion module.
- Slide expansion module into the bay and secure it with the two
screws.
Note: When the expansion module is installed, the mic+music will be overlaid on any other input source in use.
DELAYMIC 1
MIC MASTER
PEAK
PEAK
USB MP3
POWER
AUX
MIC 2 REPEAT MID
BASS
CASAMAN
ECHOREVERB
HEADPHONE
STEREO
MP3
Designed in California
Assembled in Taiwan
Stereo Music
Expansion Port
Wireless Microphone Port
by
MPX
TREBLE
MUSIC
DELAYMIC 1
MIC MASTER
PEAK
PEAK
USB MP3
POWER
AUX
MIC 2 REPEAT MID
BASS
CASAMAN
ECHOREVERB
HEADPHONE
STEREO
MP3
Designed in California
Assembled in Taiwan
Stereo Music
Expansion Port
Wireless Microphone Port
by
MPX
TREBLE
MUSIC
