If you want to change the IP mode of Video LAN, you can click “Search Device
Via Wizard” on the Device interface, and switch back to the IP mode select
interface.
Mode 2: DHCP mode.
The IP addresses of the Video LAN port, Encoder and Decoder are assigned
by the Router automatically, and the connection method is as following.
