HDMI Switcher 4x1, 4K@60Hz ARC
15
8.2 User Defined EDID Setting
Except directly invoking the embedded EDID, the specific EDID can be customized.
There are five EDID can be customized following the below operations.
1) Rename the user defined EDID according the following format.
EC_xx_xxxx_xxx.bin
EC: Represents EDID.
xx: Represents EDID ID. It is 11~15.
xxxx: Represents the video parameter.
xxx: Represents the audio format.
Example: EC_11_720P_LPCM.bin
2) Power on the switcher, and then connect the switcher to the PC with USB cable.
The PC will automatically detect a U-disk named of “BOOTDISK”.
3) Double-click the U-disk, a file named of “READY.TXT” would be showed.
4) Copy the user defined EDID (such as EC_11_720P_LPCM.bin) to the “BOOTDISK”
U-disk.
5) Reopen the U-disk to check the filename “READY.TXT” whether automatically
becomes “SUCCESS.TXT”, if yes, the user defined EDID was imported into the
switcher and saved as its corresponding EDID ID successfully.
6) Repeat the above third to fifth step to copy other user defined EDIDs to the
“BOOTDISK” U-disk.
7) Remove the USB cable, connect the adaptor to power on the switcher.
8) The new EDID also can be invoked via the 4-pin DIP switch directly. The EDID ID
and its corresponding switch status are shown in the below list.
ID
Switch Status
11
1011
12
1100
13
1101
14
1110
15
1111
