ENG VIVAX
17
► COMMON INTERFACE (CI+)
Insert the CI module for watching scrambled services like pay-tv channels or
some HD channels
NOTES
- Before you insert/remove the CI module, ensure that the TV is switched off. Then
insert the CI card into the CI module in
accordance with the Service Provider's
instr
uctions.
- Do not rep
eatedly insert or remove the Common Access Module as this ma
y
damage the inte
rface and cause a malfunction.
- You m
ust obtain a CI module and card from the serv
ice provider of the channels
you want to watch.
-
Insert the CI mo
dule with the SmartCard in the direction marked on the module
and SmartCard.
- CI is not support
ed in some countries and regions; check with your authorized
dealer.
► INPUT (
AV Composite)
Connect the Composite cable from an external A/V Device.
Use the audio and video cables to connect the external A/V device's composite
video/audio jacks to the TV's jacks. (Video = yellow, Audio Left = White, and
Audio Right = Red)
Press [Source] button, when the list of Input Source appears, press [▲/▼]
to select the source [AV] and press [ENTER] to connect.
VCR/DVD Player/Recorder/ Set-top
box/Satellite receiver/ Video cam
Connection Cables are not included
(Not included) Red (R)
(Not included) White (L)
(Not included) Yellow (Video)
RCA Cables (Not included) in set Red (R)
