ENG VIVAX

94

7.16 AUTO RESTART

MENU > FOR SERVICEMAN > AUTO RESTART

AUTO RESTART sets whether or not the unit re-applies the user interface settings

when the power returns following a power failure. Select YES to enable auto restart or

NON to disable auto restart.

If the auto restart function is enabled, when the power returns following a power

failure, the unit re-applies the user interface settings from before the power failure. If

the auto restart function is disabled, when the power returns after a power failure,

the unit won’t auto restart.

7.17 POWER INPUT LIMITATION

MENU > FOR SERVICEMAN > POWER INPUT LIMITATION

POWER INPUT LIMITATION sets the type of

power input limitation and the

setting range is 0-8. If the unit will operate at larger power input, 0 should be

selected. If the unit will operate at a lower power input, 1-8 should be selected

and the power input and capacity will decrease.

Model No.

0

1

2

3

4

5

6

7

8

4/6kW

18

16

15

14

13

12

8/10kW

19

18

16

14

12

12/14kW(1N)

30

28

26

24

22

20

18

16

16kW(1N)

30

29

27

25

23

21

19

17

12/14kW(3N)

14

13

12

11

10

9

16kW(3N)

14

13

12

11

10

9

7.18 INPUT DEFINE

MENU > FOR SERVICEMAN > INPUT DEFINE

Figure 3-7.50: INPUT DEFINE

INPUT DEFINE sets sensors and functions to fulfill with installation.

M1M2 sets the control function of M1M2 for remote ON/OFF of unit or AHS or TBH

SMART GRID sets whether SMART GRID control signal is connected to hydronic PCB.

Tw2 sets whether T1b sensor exist in the installation.

Tbt1 set whether balance tank temperature sensors are installed in the balance tank. (Tbt1 sensor, individually purchase;Tbt2,

reserved)

15 INPUT DEFINE

REMOTE

NON

ADJUST

15.1 M1M2

15.2 SMART GRID

15.3 Tw2

15.4 Tbt1

15.5 Tbt2

15 INPUT DEFINE

NON

ADJUST

15.11 PUMP_I SILENT MODE

15.12 DFT1/DFT2 DEFROST

Figure 3-7.47: AUTO RESTART menu

Figure 3-7.48: POWER INPUT LIMITATION menu

Figure 3-7.49: Limitation value (unit:A)

13 AUTO RESTART

YES

NON

ADJUST

13.1 COOL/HEAT MODE

13.2 DHW MODE

14 POWER INPUT LIMITATION

0

ADJUST

14.1 POWER INPUT LIMITATION
