ENG VIVAX

84

T4HMIN sets the ambient temperature below which the heat pump will not operate in heating mode. The lowest value

that T4CMIN can take is -25°C, which is the heating mode lower ambient temperature operating limit of the heat pump.

Refer to Figure 3-7.15.

dT1SH sets the temperature difference between the heat pump leaving water

temperature (T1) and the heat pump leaving water set temperature (T1S)

above which the heat pump provides heated water to the space heating

terminals.

dTSH sets the temperature difference between the actual room temperature (Ta) and set room temperature (TS) above

which the heat pump provides heated water to the space heating terminals. When TS – Ta ≥ dTSH the heat pump provides

heated water to the space heating terminals and when Ta ≥ TS the heat pump does not provide heated water to the space

heating terminals. Refer to Figure 3-7.16. dTSH is only relevant if YES is selected for ROOM TEMP in the TEMP. TYPE

SETTING menu. Refer to Part 3, 7.8 “TEMP. TYPE SETTING Menu”.

t_INTERVAL_H sets the heating mode compressor re-start delay. When the compressor stops running, it will not re-start

until at least t_INTERVAL_H minutes have elapsed.

T1SetH1 sets the temperature 1 of automatic setting curve for heating mode.

T1SetH2 sets the temperature 2 of automatic setting curve for heating mode.

T4H1 sets the ambient temperature 1 of automatic setting curve for heating mode.

T4H2 sets the ambient temperature 2 of automatic setting curve for heating mode.

ZONE1 H-EMISSION sets the emission type for heating mode.

ZONE2 H-EMISSION sets the emission type for heating mode.

7.7 AUTO MODE SETTING Menu

MENU > FOR SERVICEMAN > AUTO MODE SETTING

In AUTO MODE SETTING the following parameters should be set.

T4AUTOCMIN sets the ambient temperature below which the heat pump will

not provide chilled water for space cooling in auto mode. Refer to Figure 3-7.18.

T4AUTOHMAX sets the ambient temperature above which the heat pump will

not provide heated water for space heating in auto mode. Refer to Figure

3-7.18.

Figure 3-7.18: T4AUTOCMAX, T4AUTOCMIN

Abreviations:

HP

: Heat pump

AHS: Additional heating source

IBH: Backup electric heater

T4CMAX: The ambient temperature above which the heat pump will not operate in cooling mode.

T4HMIN: The ambient temperature below which the heat pump will not operate in heating mode.

Figure 3-7.16: dTSH

Note:

Only when ROOM TEMP is enabled will this function

be available

Figure 3-7.17: AUTO MODE SETTING menu

17°C

25°C

4 AUTO. MODE SETTING

4.1 T4AUTOCMIN

4.2 T4AUTOHMAX

ADJUST
