VIVAX ENG
69
2.9.2 Installation in Rows
Figure 3-2.11: Multi-row installation
Table 3-2.4: Multiple row installation spacing requirements
Model
A(mm)
B1(mm)
B2(mm)
C(mm)
4-6KW
ı
2500
ı
1000
ı
300
ı
600
8-16KW
ı
3000
ı
1500
ı
300
ı
600
2.10 Transportation support
For 12/14/16kW model, there is a transportation support which is used to protect tubes from breaking during
transportation and this support should be taken off before turning on the heat pump.
Figure 3-2.12: Remove the transportation support
