VIVAX ENG

65

2Installation

2.1 Acceptance and Unpacking

2.2 Hoisting

Figure 3-2.1: Hosting the unit

2.3 Placement Considerations

Placement of the outdoor unit should take account of the following considerations:

Outdoor units should not be exposed to direct radiation from a high-temperature heat source.

Outdoor units should not be installed in positions where dust or dirt may affect heat exchangers.

Outdoor units should not be installed in locations where exposure to oil or to corrosive or harmful gases, such as

acidic or alkaline gases, may occur.

The hook and barycenter of

the unit should be on a line

in vertical direction to

prevent improper inclination

Make the rope go through

the lifting holes from both

the right and left sides in the

wooden collet

≥1000mm

Protect Angle



When units are delivered check whether any damage occurred during shipment. If there is damage to the

surface or outside of a unit, submit a written report to the shipping company.

 Check that the model, specifications and quantity of the units delivered are as ordered.

 Check that all accessories ordered have been included. Retain the Owner's Manual for future reference.

Notes for installers

#



Do not remove any packaging before hoisting. If units are not packaged or if the packaging is damaged, use

suitable boards or packing material to protect the units.

 Hoist one unit at a time, using two ropes to ensure stability.

 Keep units upright during hoisting, ensuring that the angle to the vertical does not exceed 30°.

Notes for installers

#
