Figure 3-9.5: High temperature curves for cooling mode

1

Leaving water set temperature (⁰C )

Outdoor ambient temperature (⁰C )

Notes:

1.

It only has the curves of the high temperature setting for cooling, if the high temperature is set for cooling.

2. Curve 4 is default in high temperature cooling mode and curve 6 is default in ECO mode.

There is one customized curve which can set by user according to using habits. Users just need to input the ambient

temperature and desire water temperature for two working condition to build the customized curve. The setting of

T1SETH1, T1SETH2, T4H1, T4H2 refer to Part 3, 8.6” HEATING MODE SETTING Menu” and T1SETC1, T1SETC2, T4C1, T4C2

refer to Part 3, 8.5” COOLING MODE SETTING Menu”.

Figure 3-9.6: Automatic setting curve for heating mode

Figure 3-9.7: Automatic setting curve for cooling mode

15

17

19

21

23

25

-10-5 0 5 101520253035404550

T1S(

Ԩ

)

T4(Ԩ)

Curve 1

Curve 2

Curve 3

Curve 4

Curve 5

Curve 6

Curve 7

Curve 8

T4H1

T4H2

T1SETH2

T1SETH1

T4

T1S (T1S2)

T4C1

T4C2

T1SETC2

T1SETC1

T4

T

1S (T1S2)
